320 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Overall (1) Time Constant Ch0…3Overall.RMSTimeConstantB Dynamix AC Measurement Object AC Overall Measurement RMS TC
Ch0…3Overall.PkTimeConstantB Dynamix AC Measurement Object AC Overall Measurement Peak TC
Tracking Filters Page
Enable (0…3) Ch0…3TrkFltrs.TrkFltr0…3En Dynamix Order Measurement Object Order Measurement Configuration
Tacho Source (0…3) Ch0…3TrkFltrs.TrkFltr0…3TachSrc Dynamix Order Measurement Object Order Measurement Configuration
Order (0…3) Ch0…3TrkFltrs.TrkFltr0…3 Dynamix Order Measurement Object Order 0…3 setup
Measurement Units Ch0…3Orders.Units Dynamix Order Measurement Object Order Measurement Units
Signal Detection Ch0…3Overall.SignalDetection Dynamix Order Measurement Object Order Measurement Scaling
Measurement Resolution Speed 0 Ch0…3Overall.Speed0FilterNumRevolutions Dynamix Order Measurement Object Order Filter Definition (Tacho 0)
Measurement Resolution Speed 1 Ch0…3Overall.Speed1FilterNumRevolutions Dynamix Order Measurement Object Order Filter Definition (Tacho 1)
FFT Page
Enable TWF Data Storage Ch0…3Complex.TWFEn Dynamix Normal CM Data Object Enable
Signal Source Ch0…3Complex.Source Dynamix Normal CM Data Object Signal Source
Measurement Units Ch0…3Complex.Units Dynamix Normal CM Data Object Measurement Units
Number of Samples Ch0…3Complex.TWFSamples Dynamix Normal CM Data Object Waveform Record Length
Speed Reference Ch0…3Complex.SpeedRef Dynamix Normal CM Data Object Associated Tacho Source
Enable FFT Data Storage Ch0…3Complex.FFTEn Dynamix Normal CM Data Object Enable
Number of Spectrum Lines Ch0…3Complex.FFTNumLines Dynamix Normal CM Data Object FFT Line Resolution
Signal Detection Ch0…3Complex.FFTSignalDetection Dynamix Normal CM Data Object FFT Line Value Detection/Scaling
FFT Window Type Ch0…3Complex.FFTWindowType Dynamix Normal CM Data Object FFT Window Function
Number of Averages Ch0…3Complex.AveragesCount Dynamix Normal CM Data Object Number of Averages
Average TWF Ch0…3Complex.AvgTWFEn Dynamix Normal CM Data Object Enable
gSE Page
High Pass Filter Frequency Ch0…3Filter.HighPassFreq Dynamix Channel Setup Object HP Filter -3 dB Point
Speed Reference Ch0…3Complex.SpeedRef Dynamix Normal CM Data Object Associated Tacho Source
Maximum Frequency Ch0…3Filter.LowPassFreq Dynamix Channel Setup Object LP Filter -3 dB Point
Number of Spectrum Lines Ch0…3Complex.FFTNumLines Dynamix Normal CM Data Object FFT Line Resolution
FFT Window Type Ch0…3Complex.FFTWindowType Dynamix Normal CM Data Object FFT Window Function
Number of Averages Ch0…3Complex.AveragesCount Dynamix Normal CM Data Object Number of Averages
FFT Bands Page
Enable ModuleControl.Ch0…3DSP_FFT.En Dynamix Module Control Object Enable
Signal Source ModuleControl.Ch0…3DSP_FFT.Source Dynamix Module Control Object Signal Source
Measurement Units ModuleControl.Ch0…3DSP_FFT.Units Dynamix Module Control Object Measurement Units
Number of Spectrum Lines ModuleControl.Ch0…3DSP_FFT.FFTNumLines Dynamix Module Control Object Line Resolution
Signal Detection ModuleControl.Ch0…3DSP_FFT.SignalDetection Dynamix Module Control Object FFT Line Value Detection/Scaling
FFT Window Type ModuleControl.Ch0…3DSP_FFT.WindowType Dynamix Module Control Object Window Function
Number of Averages ModuleControl.Ch0…3DSP_FFT.AveragesCount Dynamix Module Control Object Number of Averages
Enable Ch0…3Band0…7.En Dynamix FFT Band Object Channel Source
Measurement Mode Ch0…3Band0…7.Type Dynamix FFT Band Object FFT Band magnitude - Type
Table 83 - Parameter – Tag – Object Attribute Cross-reference (continued)
Parameter Tag Member Object Attribute
