CIP Objects Appendix A
Band Limit Begin Ch0…3Band0…7.LimitBegin Dynamix FFT Band Object Start frequency in Hz
Dynamix FFT Band Object Start frequency in orders
Band Limit End Ch0…3Band0…7.LimitEnd Dynamix FFT Band Object Stop frequency in Hz
Dynamix FFT Band Object Stop frequency in orders
Domain Ch0…3Band0…7.Do main Dynamix FFT Band Object Source of band frequency limits
Speed Reference Ch0…3Band0…7.SpeedRef Dynamix FFT Band Object Tacho source for band limits
DC Page
Normal Thrust and Proportional
Voltage – Measurement Units
Ch0…3DC.Units Dynamix Transducer Object Transducer DC Units
Normal Thrust and Proportional
Voltage –Time Constant
Ch0…3DC.TimeConstant Dynamix DC Measurement Object DC Measurement TC
Normal Thrust and Proportional
Voltage – Calibration Offset
Ch0…3DC.Offset Dynamix DC Measurement Object DC Measurement Offset
Normal Thrust and Proportional
Voltage – Sense Control
Ch0…3DC.SenseControl Dynamix DC Measurement Object DC Measurement Sense Control
Rod Drop - Tachometer Ch0…3DC.RodDropTriggerSource Dynamix DC Measurement Object Rod Drop Trigger Source
Rod Drop – Target Angle Ch0…3DC.RodDropTargetAngle Dynamix DC Measurement Object Rod Drop Trigger Angle
Rod Drop –Angular Range Ch0…3DC.RodDropAngularRange Dynamix DC Measurement Object Rod Drop Measurement Range
Rod Drop – Decay Time Ch0…3DC.RodDropDecayTime Dynamix DC Measurement Object Rod Drop Decay Time
Differential Expansion – Ramp Angle Ch0_1.SensorAAngle when Channel 0 Dynamix Dual Measurement Object Sensor A Ramp Angle
Ch0_1.SensorBAngle when Channel 1 Dynamix Dual Measurement Object Sensor B Ramp Angle
Ch2_3.SensorAAngle when Channel 2 Dynamix Dual Measurement Object Sensor A Ramp Angle
Ch2_3.SensorBAngle when Channel 3 Dynamix Dual Measurement Object Sensor B Ramp Angle
Differential Expansion – Overall Axial
Offset
Ch0_1.AxialOffset when Channel 0 or 1 Dynamix Dual Measurement Object Overall Axial Offset
Ch2_3.AxialOffset when Channel 2 or 3 Dynamix Dual Measurement Object Overall Axial Offset
Differential Expansion – Overall Radial
Offset
Ch0_1.RadialOffset when Channel 0 or 1 Dynamix Dual Measurement Object Overall Radial Offset
Ch2_3.RadialOffset when Channel 2 or 3 Dynamix Dual Measurement Object Overall Radial Offset
Eccentricity - Tachometer Ch0…3Overall.ConfigurePkPerRevolution Dynamix AC Measurement Object Configure Peak Per Revolution
Eccentricity – Minimum pk/revolution Ch0…3Overall.MinPeakPerRevolutionRPM Dynamix AC Measurement Object Minimum RPM
Demand Page
Signal Source Ch0…3Demand.Source Dynamix Advanced CM Data Object Source Selection
TWF Measurement Units Ch0…3Demand.TWFUnits Dynamix Advanced CM Data Object Measurement Units
Speed Reference Ch0…3Demand.SpeedRef Dynamix Advanced CM Data Object Associated Tacho Source
Analog Output Page
Enable Ch0…3AnalogOut.En Dynamix Current Output Module
Object
Current Output Enable
Measurement Ch0…3AnalogOut.MeasurementID
See Measurement ID Definition
on page 325.
Dynamix Current Output Module
Object
Current Output Measurement
Identifier
Low Engineering Ch0…3AnalogOut.LowEngineering Dynamix Current Output Module
Object
4 mA Output Scaling
High Engineering Ch0…3AnalogOut.HighEngineering Dynamix Current Output Module
Object
20 mA Output Scaling
Table 83 - Parameter – Tag – Object Attribute Cross-reference (continued)
Parameter Tag Member Object Attribute
