Allen-Bradley 1444-TSCX02-02RB User Manual

Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 373
CIP Objects Appendix A
0x398 3 19 Measurement Units ENGUNITS
20 Associated Tacho Source SINT
21 Waveform Record Length SINT
24 FFT Enable SINT
25 FFT Line Resolution SINT
26 FFT Window Function SINT
27 FFT Averages SINT
28 FFT Line value detection/scaling SINT
- - - Pad SINT
0x398 4 16 Enable BYTE
17 Signal Source SINT
18 Number of averages SINT
- - - Pad SINT
0x398 4 19 Measurement Units ENGUNITS
20 Associated Tacho Source SINT
21 Waveform Record Length SINT
24 FFT Enable SINT
25 FFT Line Resolution SINT
26 FFT Window Function SINT
27 FFT Averages SINT
28 FFT Line value detection/scaling SINT
- - - Pad SINT
0x39A 0 16 Synchronized data control BYTE
- - - Pad SINT
- - - Pad INT
0x39A 1 16 Source Selection SINT
- - - Pad SINT
0x39A 1 17 Measurement Units ENGUNITS
18 Associated Tacho Source SINT
19 Waveform Record Length SINT
- - - Pad INT
0x39A 2 16 Source Selection SINT
- - - Pad SINT
0x39A 2 17 Measurement Units ENGUNITS
18 Associated Tacho Source SINT
19 Waveform Record Length SINT
- - - Pad INT
0x39A 3 16 Source Selection SINT
- - - Pad SINT
Table 101 - Configuration Group 19 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
