374 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
0x39A 3 17 Measurement Units ENGUNITS
18 Associated Tacho Source SINT
19 Waveform Record Length SINT
- - - Pad INT
0x39A 4 16 Source Selection SINT
- - - Pad SINT
0x39A 4 17 Measurement Units ENGUNITS
18 Associated Tacho Source SINT
19 Waveform Record Length SINT
- - - Pad INT
0x399 1 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
0x399 2 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
0x399 3 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
Table 101 - Configuration Group 19 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
