532 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
UINT ClockClass 0…255 (0: best)
UINT TimeAccuracy Index values
UINT OffsetScaledLogVariance
UINT CurrentUtcOffset seconds
WORD TimePropertyFlags
UINT TimeSource Atomic, GPS, Radio
11 Get NumberOfPorts UINT 1
12 Get PortStateInfo STRUCT
UINT NumberOfPorts 1
ARRAY
UINT PortNumber
UINT PortState Index 1… 9
13 Get NV PortEnableCfg STRUCT
UINT NumberOfPorts
ARRAY
UINT PortNumber
UINT PortEnable 1: Enabled
14 Get/Set NV PortLogAnnounceIntervalCfg STRUCT
UINT NumberOfPorts 1
ARRAY
UINT PortNumber
UINT PortLogAnnounceInterval log base 2 seconds
15 Get/Set NV PortLogSyncIntervalCfg STRUCT
UINT NumberOfPorts
ARRAY
UINT PortNumber
INT PortLogSyncInterval log base 2 seconds
18 Get/Set NV Do mainNumber USINT
19 Get ClockType WORD
20 Get manufactureIdentity USINT(4)
21 Get ProductDescription STRUCT
UDINT Size
USINT[size] Description UTF-8 Unicode
22 Get RevisionData STRUCT
UDINT Size
USINT[size] Revision UTF-8 Unicode
23 Get UserDescription STRUCT
UDINT Size
USINT[size] Description UTF-8 Unicode
Table 292 - Instance Attributes (continued)
Attribute
ID
Access
Rule
NV Name Data Type Description of Attribute Semantics of
Values
