Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 533
CIP Objects Appendix A
24 Get PortProfileIdentityInfo STRUCT
UINT NumberOfPorts
ARRAY
UINT PortNumber
USINT[8] PortProfileIdentity
25 Get PortPhysicalAddressInfo STRUCT
UINT NumberOfPorts
ARRAY
UINT PortNumber
USINT[16] PhysicalProtocol
UINT SizeOfAddress
USINT[16] PortPhysicalAddress
26 Get PortProtocolAddressInf STRUCT
UINT NumberOfPorts
ARRAY
UINT PortNumber
UINT NetworkProtocol E/IP = 1
UINT SizeOfAddress
USINT[16] PortProtocolAddress
27 Get StepsRemoved UINT Local to Grandmaster
28 Get SystemTimeAndOffset STRUCT
ULINT SystemTimeAero
ULINT SystemOffset
Table 292 - Instance Attributes (continued)
Attribute
ID
Access
Rule
NV Name Data Type Description of Attribute Semantics of
Values
Table 293 - Common Services
Service
Code
Implementation Service Name Description of Service
Class Instance
0x03 - x Get_Attributes_List
0x04 - x Set_Attributes_List
0x0E x x Get_Attribute_Single Returns the contents of the specified attribute
0x10 - x Set_Attribute_Single Sets the specified attribute
