Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 545
CIP Objects Appendix A
The left most two characters of the units ID shown in the table indicate the
class from which that unit of measurement originates. The relevant CIP
Standard and Custom EU Classes are listed in Table 316
and Table 317.
Table 316 - Standard CIP Engineering Unit Classes
Value Name
0x12 Temperature
0x13 Pressure
0x15 Acceleration
Ox17 Angle
0x1C Current
0x1F Frequency
0x22 Length
0x2B Velocity
0x2D Voltage
Table 317 - Custom CIP Engineering Unit Classes
Value Name
0x08 Length
0x09 Velocity
0x0A Bearing Defect Units
0x0B Acceleration
0x0C Pressure
0x0F Other
