Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 83
Install the Dynamix 1444 Series Monitoring System Chapter 2
TSCX Module Transducers
The TSCX supports four types of speed sensor inputs:
•Eddy Current Probe
• NPN/PNP Proximity Switch
• Self-Generating Magnetic Sensors
• TTL Signal Input
1444-TSCX02-02RB Tachometer Signal Conditioner Expansion Module
and 1444-TB-B Terminal Base
Lower Module Connector
Terminal 1 2 3 4 5 6
Name TXP 0 SIG 0 RET 0 TXP 1 SIG 1 RET 1
Application Tach 0 Input Tach 1 Input
Description Transducer 0 Power Transducer 0 Signal Transducer 0 Return Transducer 1 Power Transducer 1 Signal Transducer 1 Return
Lower Base Connector
Terminal 7 8 9 10 11 12
Name SH SH NOT USED SH SH
Application Shield Shield
Description Cable shield connection points Do not connect Cable shield connection points
