Allen-Bradley 1788-EN2DNR - Certifications; Specifications

16 Rockwell Automation Publication 1788-UM059B-EN-P - September 2015
Chapter 2 Install the 1788-EN2DNROM Linking Device
Certifications
Specifications
Certification (when product
is marked)
(1)
(1) See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates, and other certification details.
Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584.
CE
European Union 2004/108/EC EMC Directive, compliant with:
• EN 61000-6-4, Emission standard for industrial environment
• EN 61000-6-2, Immunity for industrial environment
• EN61326-1, Meas./Control/Lab., Industrial Requirements
• EN61131-2, Programmable Controllers (Clause 8, Zone A & B)
European Union 2011/65/EU RoHS, compliant with:
• EN50581, Technical documentation
RCM Australian Radiocommunications Act, compliant with:
• EN 61000-6-4; Industrial Emissions
KC Korean Registration of Broadcasting and Communications Equipment, compliant with:
• Article 58-2 of Radio Waves Act, Clause 3
EtherNet/IP ODVA conformance tested to EtherNet/IP specifications.
DeviceNet ODVA conformance tested to DeviceNet specifications.
Attribute 1788-EN2DNROM
Temperature, operating
• IEC 60068-2-1 (Test Ad, Operating Cold)
• IEC 60068-2-2 (Test Bd, Operating Dry Heat)
• IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0…60 °C (32…140 °F)
Temperature, nonoperating
• IEC 60068-2-1 (Test Ab, Nonoperating Cold)
• IEC 60068-2-2 (Test Bb, Nonoperating Dry Heat)
• IEC 60068-2-14 (Test Na, Nonoperating Thermal Shock)
-40…85 °C (-40…185 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Unit power supply 24V DC SELV/PELV (-15…20%)
100 mA @ 24V DC, max
DeviceNet power 24V DC SELV/PELV
20 mA @ 24V DC, max
Enclosure type rating Meets IP67 and UL Type 4/4X
Use dust caps on unused switches and connectors
Shock, operating/nonoperating
• IEC60068-2-27 (Test Ea, Unpackaged Shock)
30 g
Vibration
• IEC60068-2-6 (Test Fc, Operating)
5 g @ 10...500 Hz
Relative humidity
• IEC60068-2-30 (TestDb, Unpackaged Damp Heat)
5...95% noncondensing
Wiring category
(1)
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding
Guidelines, publication 1770-4.1.
3 - on USB ports, 2 - on power ports, 2 - on communication ports
