44 Rockwell Automation Publication 1788-UM059B-EN-P - September 2015
Chapter 3 Install the 1788-EN2DNR Linking Device
Register the EDS File
The EDS file for the linking device is accessible and downloadable with RSLinx
software. To register the EDS file in RSLinx software, follow these steps.
1. In RSLinx software, right-click the linking device.
2. Select Upload EDS File from Device.
3. Click Next or Finish for the remaining dialog boxes.
