64 Rockwell Automation Publication 1788-UM059B-EN-P - September 2015
Chapter 6 SD Card
2. Open the latch situated on the linking device and insert or remove the
SD card.
3. Close the SD card latch.
Load or Store to the SD Card
Using RSLogix 5000 software, the SD card can be used to load or store the
linking device’s configuration. Note that the SD card does not store the scan list
created by RSNetWorx for DeviceNet software.
Store to the SD Card
To store the linking device’s configuration to the SD card, the SD card must be
correctly inserted and unlocked.
Clicking Store to SD Card produces this warning.
Clicking Yes stores the current configuration of the linking device to the SD card.
