Allen-Bradley 5069-OBV8S User Manual

Rockwell Automation Publication 5069-UM004A-EN-P - April 2019 239
Module Tag Definitions Appendix B
Ptxx.InputOffOnFilter SINT The amount of time that a signal must be in the on state
before the input data indicates the on state. The amount
of time is indicated using an enumeration. Not all
products support all enumeration values.
5 = 0 μs
6 = 5 μs
7 = 10 μs
8 = 20 μs
9 = 50 μs
10 = 100 μs
11 = 200 μs
12 = 500 μs
13 = 1 ms
14 = 2 ms
15 = 5 ms
16 = 10 ms
17 = 20 ms
18 = 50 ms
Ptxx.InputOnOffFilter SINT The amount of time that a signal must be in the off state
before the input data indicates the off state. The amount
of time is indicated using an enumeration. Not all
products support all enumeration values.
5 = 0 μs
6 = 5 μs
7 = 10 μs
8 = 20 μs
9 = 50 μs
10 = 100 μs
11 = 200 μs
12 = 500 μs
13 = 1 ms
14 = 2 ms
15 = 5 ms
16 = 10 ms
17 = 20 ms
18 = 50 ms
Ptxx.ChatterTime INT A value from 1…10000 ms in whole ms increments. 1…10000
Ptxx.ChatterCount SINT The number of input changes that are considered Chatter. • 0 = Disabled
• 2…127 = Enabled
Ptxx.CaptureOffOnEn BOOL Enables capturing Off to On time stamps. If cleared, the
point does not record Off to On time stamps.
• 0 = Capture disabled (default) for OFF to ON
input transitions
• 1 = Capture enabled for OFF to ON input
transitions
Ptxx.CaptureOnOffEn BOOL Enables capturing On to Off time stamps. If cleared, the
point does not record On to Off time stamps.
• 0 = Capture disabled (default) for ON to OFF
input transitions
• 1 = Capture enabled for ON to OFF input
transitions
Table 64 - 5069-IB16F Module Configuration Tags
Name Size Definition Valid Values

Allen-Bradley 5069-OBV8S Specifications

General

Brand	Allen-Bradley
Model	5069-OBV8S
Category	I/O Systems
Language	English
