ASCII Serial Communications Chapter 12
To change a specific setting, enter the command shown in Table 111.
Table 111 - SET Command Format
SET n s TERSE
Where:
n is left blank to enter RELAY settings.
n is P to enter front panel serial port settings.
n is M to enter I/O mapping settings.
s is the name of the specific setting you want to jump to and begin setting.
If s is not entered, the relay starts at the first setting (e.g., enter 50P1P to start at Short Circuit
Trip level setting).
TERSE instructs the relay to skip the settings display after the last setting.
Use this parameter to speed up the SET command.
If you want to review the settings before saving, do not use the TERSE option.
