Kinetix 5500 Drive Systems
Bulletin VPAR Performance Specifications with Kinetix 5500 Drives
Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient, and rated line voltage. For
additional information on ambient and line conditions, refer to Motion Analyzer software.
Electric Cylinder
Cat. No.
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(240V AC input)
VPAR-A1xxxB 150 0.88 240 (53.9) 2.90 300 (67.4) 0.11 2198-H008-ERSx
VPAR-A1xxxE 500 1.66 280 (62.9) 2.90 350 (78.7) 0.23 2198-H008-ERSx
VPAR-A2xxxC 250 1.74 420 (94.4) 3.72 525 (118) 0.25 2198-H008-ERSx
VPAR-A2xxxF 640 4.45 640 (144) 8.40 800 (180) 0.56 2198-H015-ERSx
VPAR-A3xxxE 500 12.30 2000 (450) 31.70 2500 (562) 1.30 2198-H040-ERSx
VPAR-A3xxxH 1000 13.50 1284 (289) 27.00 1625 (365) 1.56 2198-H040-ERSx
Electric Cylinder
Cat. No.
Speed, max
mm/s (in/s)
System Continuous
Stall Current
Amps 0-pk
System Continuous
Stall Force
N (lb)
System Peak
Stall Current
Amps 0-pk
System Peak
Stall Force
N (lb)
Motor Output
Power Rating
kW
Kinetix 5500 Drives
(480V AC input)
VPAR-B1xxxB 150 0.41 240 (53.9) 1.34 300 (67.4) 0.11 2198-H003-ERSx
VPAR-B1xxxE 500 1.20 280 (62.9) 2.10 350 (78.7) 0.24 2198-H003-ERSx
VPAR-B2xxxC 250 1.25 420 (94.4) 2.67 525 (118) 0.25 2198-H003-ERSx
VPAR-B2xxxF 640 3.10 640 (144) 5.80 800 (180) 0.56 2198-H008-ERSx
VPAR-B3xxxE 500 5.10 2000 (450) 13.0 2500 (562) 1.30 2198-H015-ERSx
VPAR-B3xxxH 1000 8.60 1284 (289) 17.0 1625 (365) 1.68 2198-H015-ERSx
