32 Rockwell Automation Publication KNX-RM009C-EN-P - May 2019

Kinetix 5500 Drive Systems

Kinetix 5500 (200V-class operation) Drives with Kinetix VP Food Grade Motors

This section provides system combination information for the Kinetix 5500 drives (with 200 and 240V, nominal input)

when matched with Kinetix VP (200V-class) food-grade motors. Single cable catalog numbers, system performance

specifications, and the optimum torque/speed curves are included.

Kinetix 5500 servo drives are capable of 200V or 400V-class operation. These system performance tables and torque/

speed curves reflect single-phase and three-phase drive operation with 200V-class motors; however, only

2198-H003-ERSx, 2198-H008-ERSx, and 2198-H015-ERSx drives are capable of single-phase operation.

Bulletin VPF Motor Cable Combinations

Rotary Motor (200V-class)

Cat. No.

Single Cable Cat. No.

(1)

(1) Use 2090-CSxM1DF or 2090-CSxM1DG cables. Cable length xx is in meters, 01 (3.3)…50 (164) in 1.0 m (3.3 ft) increments. Refer to the Kinetix Motion Accessories Technical Data, publication

KNX-TD004

, for cable specifications. For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Single Motor Cable Overview beginning on page 13.

Feedback Type

VPF-A0632F, VPF-A0633C, VPF-A0633F

2090-CSBM1Dx-18AAxx or

2090-CSWM1Dx-18AAxx (standard, non-flex)

2090-CSBM1Dx-18AFxx (continuous-flex)

Multi-turn or Single-turn

Digital Encoder Feedback

VPF-A0752C, VPF-A0753C

VPF-A1001C

VPF-A0752E, VPF-A0753E

2090-CSBM1Dx-14AAxx or

2090-CSWM1Dx-14AAxx (standard, non-flex)
