Allen-Bradley Kinetix 5500 Design Guide

Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 47
Kinetix 5500 Drive Systems
Kinetix 5500 (400V-class) Drives with Kinetix VP Hygienic Stainless Steel Motors
This section provides system combination information for the Kinetix 5500 drives (with 480V, nominal input) when
matched with Kinetix VP (400V-class) hygienic stainless-steel motors. Single cable catalog numbers, system performance
specifications, and optimum torque/speed curves are included.
Bulletin VPH Motor Cable Combinations
Bulletin VPH (non-brake) Motor Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Rotary Motor (400V-class)
(1)
Cat. No.
(1) The VPH-B100xx, VPH-B115xx, and VPH-B130xx frame on-motor cables include 14 AWG conductors and are also compatible with 2090-CSxM1Dx-14Axxx cable.
Single Cable Cat. No.
(2)
(2) Use 2090-CSxM1DF or 2090-CSxM1DG cables. Cable length xx is in meters, 01 (3.3)…50 (164) in 1.0 m (3.3 ft) increments. Refer to the Kinetix Motion Accessories Technical Data, publication
KNX-TD004
, for cable specifications. For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Single Motor Cable Overview beginning on page 13.
Feedback Type
VPH-B0632T, VPH-B0633M
2090-CSBM1Dx-18AAxx or
2090-CSWM1Dx-18AAxx (standard, non-flex)
2090-CSBM1Dx-18AFxx (continuous-flex)
Multi-turn or Single-turn
Digital Encoder Feedback
VPH-B0753F
VPH-B1001F, VPH-B1003F
VPH-B1152F, VPH-B1153E
VPH-B1304E
VPH-B1653D
2090-CSBM1Dx-14AAxx or
2090-CSWM1Dx-14AAxx (standard, non-flex)
2090-CSBM1Dx-14AFxx (continuous-flex)
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(480V AC operation)
VPH-B0632T-xxx2 8000 8000 1.73 0.84 (7.5)
8.80 2.37 (21.0)
0.52 (0.69)
2198-H008-ERSx
10.30 2.76 (24.4) 2198-H015-ERSx
VPH-B0633M-xxx2 6700 6700 1.45 1.03 (9.2) 8.75 4.16 (36.8) 0.50 (0.67) 2198-H008-ERSx
VPH-B0753F-xxx2 6600 6600 2.60 1.87 (16.6)
8.80 3.41 (30.2)
0.74 (0.99)
2198-H008-ERSx
18.90 7.30 (64.6) 2198-H025-ERSx
VPH-B1001F-xxx2 5000 5000 1.55 1.44 (12.8) 7.80 3.90 (34.5) 0.70 (0.93) 2198-H008-ERSx
VPH-B1003F-xxx2 4750 4750 3.49 3.43 (30.4)
17.70 10.33 (91.4)
1.36 (1.83)
2198-H015-ERSx
20.20 11.80 (104) 2198-H025-ERSx
VPH-B1152F-xxx2 4500 4500 3.64 4.03 (35.7)
17.70 12.11 (107)
1.37 (1.84)
2198-H015-ERSx
21.90 15.00 (133) 2198-H025-ERSx
VPH-B1153E-xxx2 3900 5000 5.02 5.13 (45.4)
17.70 10.93 (96.7)
1.27 (1.70)
2198-H015-ERSx
34.60 21.40 (189) 2198-H040-ERSx
VPH-B1304E-xxx2 3500 3500 5.73 8.41 (74.5)
17.70 14.43 (128)
2.15 (2.88)
2198-H015-ERSx
37.00 30.20 (267) 2198-H040-ERSx
VPH-B1653D-xxx2 3000 3000 10.41 18.67 (165)
28.30 27.14 (240)
3.16 (4.23)
2198-H025-ERSx
76.60 73.50 (651) 2198-H070-ERSx
