Allen-Bradley Kinetix 5500 Design Guide

48 Rockwell Automation Publication KNX-RM009C-EN-P - May 2019
Kinetix 5500 Drive Systems
Bulletin VPH (brake) Motor Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(480V AC operation)
VPH-B0632T-xxx4 7200 8000 1.72 0.80 (7.1)
8.80 2.37 (21.0)
0.40 (0.54)
2198-H008-ERSx
10.30 2.76 (24.4) 2198-H015-ERSx
VPH-B0633M-xxx4 6700 6700 1.39 1.01 (8.9) 8.75 4.16 (36.8) 0.50 (0.67) 2198-H008-ERSx
VPH-B0753F-xxx4 6600 6600 2.47 1.81 (16.0)
8.80 3.41 (30.2)
0.68 (0.92)
2198-H008-ERSx
18.90 7.30 (64.6) 2198-H025-ERSx
VPH-B1001F-xxx4 5000 5000 1.56 1.42 (12.6) 7.80 3.90 (34.5) 0.68 (0.91) 2198-H008-ERSx
VPH-B1003F-xxx4 4750 4750 3.46 3.29 (29.1)
17.70 10.33 (91.4)
1.16 (1.56)
2198-H015-ERSx
20.20 11.80 (104) 2198-H025-ERSx
VPH-B1152F-xxx4 4500 4500 3.89 4.03 (35.7)
17.70 12.11 (107)
1.37 (1.84)
2198-H015-ERSx
21.90 15.00 (133) 2198-H025-ERSx
VPH-B1153E-xxx4 3900 5000 4.99 5.13 (45.4)
17.70 10.93 (96.7)
1.08 (1.45)
2198-H015-ERSx
34.60 21.40 (189) 2198-H040-ERSx
VPH-B1304E-xxx4 3500 3500 5.85 8.24 (73.0)
17.70 14.43 (128)
1.76 (2.36)
2198-H015-ERSx
37.00 30.20 (267) 2198-H040-ERSx
VPH-B1653D-xxx4 3000 3000 10.55 18.67 (165)
28.30 27.14 (240)
2.91 (3.91)
2198-H025-ERSx
76.60 73.50 (651) 2198-H070-ERSx
