Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 43
Kinetix 5500 Drive Systems
Kinetix 5500 (200V-class) Drives with Kinetix VP Hygienic Stainless Steel Motors
This section provides system combination information for the Kinetix 5500 drives (with 240V, nominal input) when
matched with Kinetix VP (200V-class) hygienic stainless-steel motors. Single-cable catalog numbers, system performance
specifications, and optimum torque/speed curves are included.
Kinetix 5500 servo drives are capable of 200V or 400V-class operation. These system performance tables and torque/
speed curves reflect single-phase and three-phase drive operation with 200V-class motors; however, only
2198-H003-ERSx, 2198-H008-ERSx, and 2198-H015-ERSx drives are capable of single-phase operation.
Bulletin VPH Motor Cable Combinations
Bulletin VPH (non-brake) Motor Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Rotary Motor (200V-class)
(1)
Cat. No.
(1) The VPH-A115xx frame on-motor cables include 14 AWG conductors and are also compatible with 2090-CSxM1Dx-14Axxx cable.
Single Cable Cat. No.
(2)
(2) Use 2090-CSxM1DF or 2090-CSxM1DG cables. Cable length xx is in meters, 01 (3.3)…50 (164) in 1.0 m (3.3 ft) increments. Refer to the Kinetix Motion Accessories Technical Data, publication
KNX-TD004
, for cable specifications. For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Single Motor Cable Overview beginning on page 13.
Feedback Type
VPH-A0633F
VPH-A0753F
2090-CSBM1Dx-18AAxx or
2090-CSWM1Dx-18AAxx (standard, non-flex)
2090-CSBM1Dx-18AFxx (continuous-flex)
Multi-turn or Single-turn
Digital Encoder Feedback
VPH-A1003F
2090-CSBM1Dx-14AAxx or
2090-CSWM1Dx-14AAxx (standard, non-flex)
2090-CSBM1Dx-14AFxx (continuous-flex)
VPH-A1152E
VPH-A1153C
2090-CSBM1Dx-18AAxx or
2090-CSWM1Dx-18AAxx (standard, non-flex)
2090-CSBM1Dx-18AFxx (continuous-flex)
VPH-A1304D
2090-CSBM1Dx-14AAxx or
2090-CSWM1Dx-14AAxx (standard, non-flex)
2090-CSBM1Dx-14AFxx (continuous-flex)
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(240V AC operation)
VPH-A0633F-xxx2 4500 4500 2.06 1.09 (9.7)
8.80 2.79 (24.7)
0.45 (0.61)
2198-H008-ERSx
13.60 4.30 (38.1) 2198-H015-ERSx
VPH-A0753F-xxx2 4600 4600 3.73 1.90 (16.8)
17.70 4.88 (43.2)
0.68 (0.92)
2198-H015-ERSx
25.34 7.00 (62.0) 2198-H025-ERSx
VPH-A1003F-xxx2 5500 5500 8.45 3.41 (30.1)
28.3 4.97 (44.0)
1.32 (1.77)
2198-H025-ERSx
71.10 12.50 (111) 2198-H070-ERSx
VPH-A1152E-xxx2 3300 3300 5.66 4.04 (35.8)
17.70 7.94 (70.3)
1.07 (1.43)
2198-H015-ERSx
33.20 14.91 (132) 2198-H040-ERSx
VPH-A1153C-xxx2 2300 2300 4.99 5.17 (45.8)
17.70 11.72 (104)
1.11 (1.49)
2198-H015-ERSx
33.00 21.88 (194) 2198-H040-ERSx
VPH-A1304D-xxx2 3000 3000 10.03 8.44 (74.7)
28.30 14.00 (124)
1.79 (2.40)
2198-H025-ERSx
61.20 30.30 (268) 2198-H070-ERSx
