44 Rockwell Automation Publication KNX-RM009C-EN-P - May 2019
Kinetix 5500 Drive Systems
Bulletin VPH (brake) Motor Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(240V AC operation)
VPH-A0633F-xxx4 4500 4500 2.06 1.07 (9.5)
8.80 2.79 (24.7)
0.43 (0.57)
2198-H008-ERSx
13.60 4.30 (38.1) 2198-H015-ERSx
VPH-A0753F-xxx4 4600 4600 3.53 1.73 (15.3)
17.70 4.88 (43.2)
0.60 (0.80)
2198-H015-ERSx
25.34 7.00 (62.0) 2198-H025-ERSx
VPH-A1003F-xxx4 5500 5500 8.27 3.18 (28.2)
28.30 4.97 (44.0)
1.06 (1.42)
2198-H025-ERSx
71.10 12.50 (111) 2198-H070-ERSx
VPH-A1152E-xxx4 3300 3300 5.54 4.00 (35.4)
17.70 7.94 (70.3)
1.07 (1.43)
2198-H015-ERSx
33.20 14.91 (132) 2198-H040-ERSx
VPH-A1153C-xxx4 2300 2300 4.90 5.03 (44.5)
17.70 11.72 (104)
1.11 (1.49)
2198-H015-ERSx
33.00 21.88 (194) 2198-H040-ERSx
VPH-A1304D-xxx4 3000 3000 9.70 8.27 (73.2)
28.30 14.00 (124)
1.79 (2.40)
2198-H025-ERSx
61.20 30.30 (268) 2198-H070-ERSx
