Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 105

Kinetix 5500 Drive Systems

Kinetix 5500 Drives with Kinetix VP Electric Cylinders

This section provides system combination information for the Kinetix 5500 drives (with 240V and 480V, nominal

input) when matched with Kinetix VP electric cylinders. Included are motor power/brake and feedback cable catalog

numbers, system performance specifications, and the optimum force/velocity curves.

Bulletin VPAR Cable Combinations

Kinetix VP Electric Cylinders (200V-class)

Kinetix VP Electric Cylinders (400V-class)

Electric Cylinder Cat. No. Single Motor Cable

(1)

(1) Use 2090-CSxM1DF or 2090-CSxM1DG cables. Cable length xx is in meters, 01 (3.3)…50 (164) in 1.0 m (3.3 ft) increments. Refer to the Kinetix Motion Accessories Technical Data, publication

KNX-TD004

, for cable specifications. For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Single Motor Cable Overview beginning on page 13.

Feedback Type

VPAR-A1xxxB

VPAR-A1xxxE

VPAR-A2xxxC

2090-CSBM1Dx-18AAxx or

2090-CSWM1Dx-18AAxx (standard, non-flex)

2090-CSBM1Dx-18AFxx (continuous-flex)

Absolute, Multi-turn Digital Encoder,

(Hiperface DSL Protocol)

VPAR-A2xxxF

VPAR-A3xxxE

VPAR-A3xxxH

2090-CSBM1Dx-14AAxx or

2090-CSWM1Dx-14AAxx (standard, non-flex)

2090-CSBM1Dx-14AFxx (continuous-flex)

Electric Cylinder Cat. No. Single Motor Cable

(1)

(1) Use 2090-CSxM1DF or 2090-CSxM1DG cables. Cable length xx is in meters, 01 (3.3)…50 (164) in 1.0 m (3.3 ft) increments. Refer to the Kinetix Motion Accessories Technical Data, publication

KNX-TD004

, for cable specifications. For cable configuration illustrations and feature descriptions, by catalog number, refer to 2090-Series Single Motor Cable Overview beginning on page 13.

Feedback Type

VPAR-B1xxxB

VPAR-B1xxxE

VPAR-B2xxxC

VPAR-B2xxxF

2090-CSBM1Dx-18AAxx or

2090-CSWM1Dx-18AAxx (standard, non-flex)

2090-CSBM1Dx-18AFxx (continuous-flex)

Absolute, Multi-turn Digital Encoder,

SIL 2/PLd Rated,

(Hiperface DSL Protocol)

VPAR-B3xxxE
