Allen-Bradley Kinetix 5500 Design Guide

Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 33
Kinetix 5500 Drive Systems
Performance specification data and curves reflect nominal system performance of a typical system with the motor at 40 °C (104 °F) and the drive at 50 °C (122 °F) ambient, and rated line voltage. For
additional information on ambient and line conditions, refer to Motion Analyzer software.
Bulletin VPF Motor Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW (Hp)
Kinetix 5500 Drives
(240V AC Input)
VPF-A0632F 4800 4800 2.55 0.93 (8.0) 8.75 2.69 (24.0) 0.36 (0.48) 2198-H008-ERSx
VPF-A0633C 3000 3000 2.50 1.27 (11.0) 8.75 4.09 (36.0) 0.37 (0.50) 2198-H008-ERSx
VPF-A0633F 4500 4500 3.52 1.27 (11.0)
8.80 2.87 (25.0)
0.47 (0.63)
2198-H008-ERSx
12.60 4.09 (36.0) 2198-H015-ERSx
VPF-A0752C 3300 3300 3.80 1.61 (14.0) 13.30 4.39 (39.0) 0.49 (0.66) 2198-H015-ERSx
VPF-A0752E 4800 4800 4.90 1.61 (14.0)
17.70 4.10 (36.0)
0.63 (0.84)
2198-H015-ERSx
18.90 4.39 (39.0) 2198-H025-ERSx
VPF-A0753C 3300 3300 4.09 2.16 (19.0)
17.70 6.55 (58.0)
0.59 (0.79)
2198-H015-ERSx
18.90 7.02 (62.0) 2198-H025-ERSx
VPF-A0753E 4600 4600 6.12 2.28 (20.0)
17.70 5.13 (45.0)
0.76 (1.02)
2198-H015-ERSx
25.34 7.35 (65.0) 2198-H025-ERSx
VPF-A1001C 2800 2800 3.61 1.93 (17.0)
8.80 3.22 (28.0)
0.56 (0.75)
2198-H008-ERSx
10.38 3.78 (33.0) 2198-H015-ERSx
VPF-A1001M 6500 6500 7.15 1.95 (17.0)
17.70 3.31 (29.0)
1.29 (1.73)
2198-H015-ERSx
20.20 3.78 (33.0) 2198-H025-ERSx
VPF-A1002C 3000 3000 6.24 3.39 (30.0)
17.70 6.80 (60.0)
1.03 (1.38)
2198-H015-ERSx
20.33 7.82 (69.0) 2198-H025-ERSx
VPF-A1002F 5000 5000 10.04 3.26 (29.0)
28.30 6.77 (60.0)
1.60 (2.14)
2198-H025-ERSx
34.30 7.82 (69.0) 2198-H040-ERSx
VPF-A1003C 2250 2250 6.14 4.18 (37.0)
17.70 9.76 (86.0)
0.83 (1.11)
2198-H015-ERSx
20.20 11.15 (99.0) 2198-H025-ERSx
VPF-A1003E 3750 3750 9.58 4.18 (37.0)
28.30 9.76 (86.0)
1.25 (1.67)
2198-H025-ERSx
28.80 11.15 (99.0) 2198-H040-ERSx
VPF-A1003F 5500 5500 15.62 4.18 (37.0)
45.90 10.25 (90.0)
1.81 (2.42)
2198-H040-ERSx
50.0 11.15 (99.0) 2198-H070-ERSx
VPF-A1153C 2300 2300 8.88 6.50 (58.0)
28.30 18.30 (162)
1.16 (1.56)
2198-H025-ERSx
33.0 20.33 (180) 2198-H040-ERSx
VPF-A1303B 1950 1950 10.34 8.80 (78.0)
28.30 19.85 (175)
1.53 (2.05)
2198-H025-ERSx
31.0 20.72 (183) 2198-H040-ERSx
VPF-A1303F 4000 4000 18.60 7.75 (69.0)
45.90 15.36 (136)
2.25 (3.02)
2198-H040-ERSx
62.0 20.72 (183) 2198-H070-ERSx
VPF-A1304A 1600 1600 9.43 10.29 (91.0)
28.30 25.03 (221)
1.47 (1.98)
2198-H025-ERSx
33.76 28.45 (252) 2198-H040-ERSx
VPF-A1304D 3000 3000 18.40 10.20 (90.0)
45.90 21.48 (190)
1.98 (2.65)
2198-H040-ERSx
58.0 27.10 (240) 2198-H070-ERSx
