Rockwell Automation Publication KNX-RM009C-EN-P - May 2019 59
Kinetix 5500 Drive Systems
Bulletin MPL Motor Performance Specifications with Kinetix 5500 (400V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5500
(480V AC input)
MPL-B1510V 8000 8000 0.95 0.26 (2.3) 3.10 0.77 (6.8) 0.16 2198-H003-ERSx
MPL-B1520U 7000 7000 1.80 0.49 (4.3) 6.10 1.58 (13.9) 0.27 2198-H008-ERSx
MPL-B1530U 7000 7000 2.0 0.90 (8.0) 7.20 2.82 (24.9) 0.39 2198-H008-ERSx
MPL-B210V 8000 8000 1.75 0.55 (4.9) 5.80 1.52 (13.4) 0.37 2198-H008-ERSx
MPL-B220T 6000 6000 3.30 1.61 (14.2)
8.80 3.67 (32.5)
0.62
2198-H008-ERSx
11.3 4.74 (41.9) 2198-H015-ERSx
MPL-B230P 5000 5000 2.60 2.10 (18.6)
8.80 6.39 (56.6)
0.86
2198-H008-ERSx
11.3 8.20 (73.0) 2198-H015-ERSx
MPL-B310P 5000 5000 2.4 1.6 (14.1) 7.10 3.6 (32) 0.77 2198-H008-ERSx
MPL-B320P 5000 5000 4.5 3.10 (27) 14.0 8.2 (72.5) 1.5 2198-H015-ERSx
MPL-B330P 5000 5000 6.1 4.18 (37)
17.7 10.4 (92.0)
1.8
2198-H015-ERSx
19.0 11.1 (98) 2198-H025-ERSx
MPL-B420P 5000 5000 6.3 4.74 (42)
17.7 11.3 (100)
1.9
2198-H015-ERSx
22.0 13.5 (119) 2198-H025-ERSx
MPL-B430P 5000 5000 9.2 6.55 (58)
28.3 17.6 (156)
2.2
2198-H025-ERSx
32.0 19.8 (175) 2198-H040-ERSx
MPL-B4530F 3000 3000 6.7 8.36 (74)
17.7 17.7 (157)
2.1
2198-H015-ERSx
21.0 20.3 (180) 2198-H025-ERSx
MPL-B4530K 4000 4000 9.9 8.25 (73)
28.3 18.7 (166)
2.6
2198-H025-ERSx
31.0 20.3 (179) 2198-H040-ERSx
MPL-B4540F 3000 3000 9.1 10.20 (90)
28.3 26.2 (232)
2.6
2198-H025-ERSx
29.0 27.1 (240) 2198-H040-ERSx
MPL-B4560F 3000 3000
11.3 13.85 (123) 28.3 28.4 (251)
3.2
2198-H025-ERSx
11.8 14.0 (124) 36.0 34.4 (304) 2198-H040-ERS
x
MPL-B520K 3500 4000
11.3 10.4 (92) 28.3 20.6 (182)
3.5
2198-H025-ERSx
11.5 10.7 (95) 33.0 23.2 (205) 2198-H040-ERSx
MPL-B540D 2000 2000 10.5 19.4 (172) 23.0 41.0 (362) 3.4 2198-H025-ERSx
MPL-B540K 4000 4000 20.4 19.4 (171) 60.0 48.6 (430) 5.4 2198-H070ERSx
MPL-B560F 3000 3000 20.6 26.8 (237) 68.0 67.8 (600) 5.5 2198-H070-ERSx
MPL-B580F 3000 3000 26.0 34.0 (300) 81.3 78.9 (698) 7.1 2198-H070-ERSx
MPL-B580J 3800 3800 32.0 34.0 (301) 81.3 71.52 (633) 7.9 2198-H070-ERSx
MPL-B640F 2000 3000 32.0 36.7 (325) 65.0 72.3 (640) 6.1 2198-H070-ERSx
