Kinetix 5500 Drive Systems
Bulletin MPS Motor Performance Specifications with Kinetix 5500 (200V-class operation) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 40 °C (104 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software.
Kinetix 5500 (200V-class operation) Drives/MP-Series Stainless Steel Motor Curves
Kinetix 5500 (400V-class operation) Drives with MP-Series Stainless Steel Motors
This section provides system combination information for the Kinetix 5500 drives (with 400 and 480V, nominal input)
when matched with MP-Series (400V-class) stainless-steel motors. Included are motor power/brake and feedback cable
catalog numbers, system performance specifications, and the optimum torque/speed curves.
Rotary Motor
Cat. No.
Rated Speed
rpm
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 5500 Drives
(240V AC operation)
MPS-A330P 5000 5000 9.80 3.60 (32.0)
28.3 8.79 (77.8)
1.3
2198-H025-ERSx
38.0 11.10 (98.2) 2198-H040-ERSx
MPS-A4540F 3000 3000 14.4 8.1 (72)
45.9 22.84 (202)
1.4
2198-H040-ERSx
56.0 27.1 (240) 2198-H070-ERSx
IMPORTANT These motors require the 2198-H2DCK (series B or later) feedback converter kit.
Torque
(N•m)
Torque
(lb•in)
2198-H040-ERSx and MPS-A330P
Speed (rpm)
0
2000
4000
30001000
5000
12.0
10.0
8.0
6.0
4.0
2.0
0
106
88.5
70.8
53.1
35.4
17.7
0
Torque
(N•m)
Torque
(lb•in)
2198-H025-ERS
x and MPS-A4540F
30
25
20
15
10
5
0
265
221
177
133
88.5
44.2
0
Speed (rpm)
0 300020001000
= Intermittent operating region
= Continuous operating region
