Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 195
Configure and Start the Kinetix 5700 Drive System Chapter 6
Table 107 - Navigating the Regenerative Bus Supply Settings Menu
Settings Menu Selections Sub Menu Selections Attributes Default Description
Protected Mode
Reset
ENABLED
DISABLED
ENABLED
When Enabled (default), identity object or
safety resets are not possible when a
controller connection is open.
Network Config
ENABLED
DISABLED
ENABLED
When Enabled (default), network
configuration changes are not possible when
a controller connection is open.
Flash Update
ENABLED
DISABLED
ENABLED
When Enabled (default), firmware updates
are not possible when a controller
connection is open.
Device Config
ENABLED
DISABLED
ENABLED
When Enabled (default), only attribute
writes are possible when a controller
connection is open.
Network
->Static IP
(1)
IP address 192.168.1.1 Indicates current IP address
Subnet mask 255.255.255.000 Indicates current subnet mask
Gateway 192.168.001.001 Indicates current gateway
DHCP
On Turns DHCP on
Off Turns DHCP off
Display
Backlight Timeout
30 sec…NEVER
(NEVER=no timeout period,
the backlight is always on)
-> 3 min
(1)
Sets backlight timeout period of the display
Cyclic Data Select
(2)
-> DC BUS DC bus voltage
CONV UTIL Converter utilization in % Rated
CONV TEMP Converter temperature in °C
PWR OUT Output power in Watts
IBUS Output current in Amps
AC FREQ Input frequency in Hz
IAC LINE AC Line current in Amps
VAC LINE AC Line voltage in Volts
VBUS REF Bus Voltage Reference in Volts
ACTV PWR Active power in Watts
REACT PWR Reactive power in kVAR
PF Power Factor
ACTV IREF Active Current reference in % Rated
REACT IREF Reactive current reference in % Rated
Set Contrast -10…+10 0 Contrast setting of the display
Web
ENABLED
DISABLED
ENABLED
When Enabled (default), the drive's
diagnostic webpage is accessible.
(1) An arrow (->) appears in front of the chosen attribute indicating that this attribute is currently configured. This is also the factory default setting.
(2) The DC bus voltage is one of several cyclic data attributes. You can select any of the Cyclic Data Select attributes to be displayed on the Home screen.
