Chapter 6 Configure and Start the Kinetix 5700 Drive System
Table 108 - Navigating the iTRAK Power Supply Settings Menu
Settings Menu Selections Sub Menu Selections Attributes Default Description
Network
->Static IP
(1)
IP address 192.168.1.1 Indicates current IP address
Subnet mask 255.255.255.000 Indicates current subnet mask
Gateway 192.168.001.254 Indicates current gateway
DHCP
On Turns DHCP on
Off Turns DHCP off
Display
Backlight Timeout
30 sec…NEVER
(NEVER=no timeout period,
the backlight is always on)
-> 3 min
(1)
Sets backlight timeout period of the display
Cyclic Data Select
(2)
-> BUS VOLT
(1)
DC bus voltage in volts
OUT1 VOLT
Output 1 voltage in volts
OUT1 AMPS
Output 1 current in amps
OUT1 PWR
Output 1 power in kilowatts
OUT1 UTIL
Output 1 utilization in percent
OUT2 VOLT
Output 2 voltage in volts
OUT2 AMP
Output 2 current in amps
OUT2 PWR
Output 2 power in kilowatts
OUT2 UTIL
Output 2 utilization in percent
TOTAL PWR
Total power in kilowatts
Set Contrast -10…+10 0 Contrast setting of the display
Web
Enabled Enables the web server
->Disabled Disables the web server
(1) An arrow (->) appears in front of the chosen attribute indicating that this attribute is currently configured. This is also the factory default setting.
(2) The DC bus voltage is one of several cyclic data attributes. You can select any of the Cyclic Data Select attributes to be displayed on the Home screen.
To Next Page
