Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 193
Configure and Start the Kinetix 6500 Drive System Chapter 7
9. Click OK.
This dialog box opens asking if the
direction was correct.
10. Click Yes.
11. If the test fails, this dialog box opens.
a. Click OK.
b. Verify the Bus status indicator turned solid green during the test.
c. Verify that the Hardware Enable Input signal is applied to the axis
you are testing.
d. Verify unit values entered in the Scaling category.
e. Return to main step 7
and run the test again.
