Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 219
Troubleshoot the Kinetix 6200 and Kinetix 6500 Drive System Chapter 8
FLT S38…FUSE BLOWN
Blown Fuse
(Bus Loss)
A blown fuse was detected in the power structure.
Coast/Disable (open
contactor enable relay)
Coast/Disable (open
contactor enable relay)
FLT S41…MTR AQB STATE FL Motor Feedback State Error
The number of illegal state transitions of the AQB encoder signals has
exceeded a factory limit.
Coast/Disable Coast/Disable
FLT S41…AUX AQB STATE FL
Aux Feedback
State Error
Coast/Disable Coast/Disable
FLT S42…MTR AQB STATE UL Motor Feedback State Error Decel/Hold Coast/Disable
FLT S42…AUX AQB STATE UL
Aux Feedback
State Error
Decel/Hold Coast/Disable
FLT S43…MTR FDBK LOSS FL Feedback Loss
On sin/cos encoders, the sum of the square of the sin/cos signals has
been measured below a user limit.
On TTL encoders, the absolute value of the differential A/B signals is
below a user limit.
IMPORTANT: Motors with non-intelligent SIN/COS encoders or
incremental encoders without Hall effect sensors do not see the
feedback loss fault if the motor is running at high speed and if only
one line in the feedback cable is opened.
Coast/Disable Coast/Disable
FLT S43…AUX FDBK LOSS FL Feedback Loss Coast/Disable Coast/Disable
FLT S44…MTR FDBK LOSS UL
(Kinetix 6500 drives only)
Motor Feedback Loss Decel/Hold N/A
FLT S44…AUX FDBK LOSS UL
(Kinetix 6500 drives only)
Aux Feedback Loss Decel/Hold N/A
FLT S45…MTR FDBK COMM FL Feedback Serial Comms
The number of consecutive missed or corrupted serial data packets
from the feedback device has exceeded a factory set limit.
Coast/Disable Coast/Disable
FLT S45…AUX FDBK COMM FL Feedback Serial Comms Coast/Disable Coast/Disable
FLT S46…MTR FDBK COMM UL
(Kinetix 6500 drives only)
Motor Fdbk Serial Comms
The number of consecutive missed or corrupted serial data packets
from the feedback device has exceeded a user set limit.
Decel/Hold N/A
FLT S46…AUX FDBK COMM UL
(Kinetix 6500 drives only)
Aux Feedback Serial Comms Decel/Hold N/A
FLT S47…MTR ENC SELF TEST nn Feedback Self Test
The feedback device has detected an internal error. Sub code (nn) is
available for factory use.
Coast/Disable Coast/Disable
FLT S47…AUX ENC SELF TEST nn Feedback Self Test Coast/Disable Coast/Disable
FLT S50…POS HW OTRAVEL
Hardware Overtravel
Positive
The positive hardware overtravel input is monitored. Decel/Disable Coast/Disable
FLT S51…NEG HW OTRAVEL
Hardware Overtravel
Negative
The negative hardware overtravel input is monitored. Decel/Disable Coast/Disable
FLT S52…POS SW OTRAVEL
(Kinetix 6200 drives only)
Software Overtravel Positive The feedback position is compared to the positive limit. N/A Coast/Disable
FLT S53…NEG SW OTRAVEL
(Kinetix 6200 drives only)
Software Overtravel
Negative
The feedback position is compared to the negative limit. N/A Coast/Disable
FLT S54…POSN ERROR Excessive Position Error
The position error has exceeded a user limit for a programmable
period of time.
Coast/Disable Decel/Disable
FLT S55…VEL ERROR nn Excessive Velocity Error
The velocity error has exceeded a limit for a period of time. The nn
sub-code is defined as follows:
00:Velocity error referenced to the velocity loop feedback.
01:Velocity error referenced to the nonvelocity feedback
(in dual-feedback configurations).
Coast/Disable Decel/Disable
FLT S56…OVERTORQUE
(Kinetix 6500 drives only)
Overtorque Limit Motor torque has exceeded a user-programmable setting. Decel/Hold N/A
FLT S57…UNDERTORQUE
(Kinetix 6500 drives only)
Undertorque Limit Motor torque has fallen below a user-programmable setting. Decel/Hold N/A
FLT S60…ILLEGAL MODE Illegal Control mode An illegal mode of operation was attempted. Decel/Hold Decel/Hold
FLT S61…ENABLE INPUT Drive Enable Input
The hardware enable input was deactivated while the drive was
enabled.
Decel/Disable Decel/Disable
FLT S62…CONTROLLER
(Kinetix 6500 drives only)
Controller Initiated
Ex
ception
T
he controller has requested the drive to generate an exception. Coast/Disable N/A
Table 108 - Drive Behavior, FLT Sxx Fault Codes (continued)
Four-character Display Message
Logix Designer
Fault Message
Description
Integrated Motion
Exception Behavior
Sercos Fault Behavior
