Publication 2711P-UM001B-EN-P
5-18 Installing and Replacing Components
Installing the Remote AC
Power Supply
Connecting to AC power requires a separate Power Supply
(2711P-RSACDIN) that mounts to a DIN Rail. This power supply
converts DC power to AC power and has the following electrical input
ratings:
• 85…264 V AC (47…63 Hz)
For details on installation, refer to the installation instructions shipped
with the power supply.
Removing the Product ID
Label
If you ordered a PanelView Plus terminal with a label, you can
remove it and attach your own label.
1. Remove the Allen-Bradley label using your fingers or a tweezers.
2. Clean area with damp cloth and isopropyl alcohol.
3. Remove adhesive backing of OEM label and affix over area
where Allen-Bradley label was located.
00 - 1500 Terminals Only
