Publication 2711P-UM001B-EN-P
Terminal Connections 6-5
USB Ports
The 700 - 1500 terminals have two USB ports. The 400 - 600 terminals
have one USB port. The terminals currently support standard USB
keyboard and mouse devices (that is, HID devices) with native device
drivers. They also support some USB printers that have Printer Control
Language (PCL) capabilities. A vendor specific Windows CE driver is
required for all other USB devices.
See Appendix B for a list of compatible USB devices.
The USB device can plug into either one of the two USB ports on the
PanelView Plus 700 - 1500 terminals.
USB Connector Pinout
Pin Signal
1 USBVCC
2 USBD-
3 USBD+
4 USB-GND
WARNING
!
If you connect or disconnect the USB cable with
power applied to the PanelView Plus or the serial
device on the other end of the cable, an electrical arc
can occur. This could cause an explosion in
hazardous location installations. Be sure that power
is removed or the area is nonhazardous before
proceeding.
WARNING
!
USB devices not powered by the USB port must be
within the same enclosure and connected to a
ground system common with the terminal or the USB
devices must be used with a USB hub that provides
galvanic isolation.
4
3
2
1
4
3
2
1
700-1500 USB Ports
4
3
2
1
400-600 USB Port
