1 Publication 2711P-UM001B-EN-P
Chapter
2
Installation
Chapter Objectives
This chapter provides instructions on how to install the PanelView
Plus terminals. It provides information on:
• hazardous locations
• environment
• enclosures
• clearances
• required tools
• cutout dimensions
• mounting dimensions
• 400 - 600 panel installation
• 700 - 1500 panel installation
Hazardous Locations
This PanelView Plus terminals are suitable for use in:
• Class I, Division 2, Groups A, B, C, D
• Class II, Division 2, Groups F, G
• Class III, Division 1
• or non-hazardous locations
The following statement applies to use in hazardous locations.
Do not install the terminals in environments where atmospheric gases
have ignition temperatures less than 135 °C or 275 °F. In addition, the
PanelView Plus terminals have a temperature code of T4.
WARNING
!
Explosion Hazard
• Substitution of components may impair suitability
for hazardous locations.
• Do not disconnect equipment unless power has
been switched off and area is known to be
non-hazardous.
• Do not connect or disconnect components unless
power has been switched off.
• All wiring must comply with N.E.C. articles
501-4(b), 502-4(b), 503-3(b) as appropriate.
• Peripheral equipment must be suitable for the
location it is used in.
