Publication 2711P-UM001B-EN-P
1-12 Overview
Catalog Number
Configuration
The following table shows the catalog number configuration for
PanelView Plus terminals.
PanelView Plus Product
Components
All of the components listed in this section are available as separate
catalog numbers for field installation or replacement.
Display Modules (700 - 1500 only)
Input
Type
Display
Size
Display Type Communications Power Memory
Flash/RAM
(1)
Label
||| | | | |
2711P- K = Keypad 4 = 3.7 inch C = Color PanelView Plus 400 and 600 Terminals A = AC 1= 32 MB/64 MB Blank =AB Label
T = Touch 6 = 5.5 inch M=Grayscale 1 = Remote I/O (single rack), ENet, RS-232 & USB
B = AC (DIN Mtb.)
(1)
2 = 128MB/128 MB
(1)
N = No Label
B = Key & Touch 7 = 6.5 inch 3 = DH-485, ENet, RS-232 & USB D = DC
10 = 10.4 inch 5 = RS-232 & USB
12 = 12.1 inch 8 = DH+, ENet, RS-232 & USB
15 = 15 inch 20 = ENet, RS-232 & USB
PanelView Plus 700 - 1500 Terminals
4 = ENet, RS-232 & (2) USB
6 = DH+, DH-485, RIO, ENet, RS-232 & (2) USB
15 = CNet, ENet, RS-232 & (2) USB
(1)
Applies to PanelView Plus 700-1500 terminals only.
Cat. No. Description
2711P-RDK7C 700 Keypad Color Display
2711P-RDT7C 700 Touch Color Display
2711P-RDB7C 700 Keypad and Touch Color Display
2711P-RDK10C 1000 Keypad Color Display
2711P-RDT10C 1000 Touch Color Display
2711P-RDB10C 1000 Keypad and Touch Color Display
2711P-RDK12C 1250 Keypad Color Display
2711P-RDT12C 1250 Touch Color Display
2711P-RDB12C 1250 Keypad and Touch Color Display
2711P-RDK15C 1500 Keypad Color Display
2711P-RDT15C 1500 Touch Color Display
2711P-RDB15C 1500 Keypad and Touch Color Display
