Publication 2711P-UM001B-EN-P
Applying Power 3-5
Connecting AC Power
The PanelView Plus 400 - 600 terminals are available with an
integrated AC power supply. A DIN Rail mounted AC power supply is
available as a separate catalog number for the PanelView Plus 700 -
1500 terminals.
The input power terminal block on the PanelView Plus 400-600
integrated power supply is removable and supports these wire sizes:
PanelView Plus 400 and 600 terminals using AC power are EN 61131-2
Equipment Class I devices.
Power Type Terminal Input Range
AC
400 - 600 85…264V ac (47…63 Hz)
60 VA maximum
700 - 1500
(1)
(1)
Requires the DIN Rail Mounted AC power supply (2711P-RSACDIN). For more information, see installation
instructions shipped with power supply.
85…264V ac (47…63 Hz)
120 VA maximum
Terminal Wire Type
Wire Size
(2-wire maximum per terminal)
Terminal Block
Screw Torque
400 - 600 Stranded or Solid #18 to #12 AWG .23 - .45 N•m (2 - 4 in-lbs)
ATTENTION
!
Explosion Hazard - Do not connect or disconnect
equipment while circuit is live unless area is known
to be non-hazardous.
Disconnect all power before installing or replacing
components. Failure to disconnect power may result
in electrical shock and/or damage to the terminal.
ATTENTION
!
Improper wiring of power terminals may result in
voltage at the communication connector shells. Refer
to the following figure when wiring.
Do not apply power to the terminal until all wiring
connections have been made. Failure to do so may
result in electrical shock.
