Allen-Bradley PanelView Plus 2711P User Manual

Publication 2711P-UM001B-EN-P
Terminal Connections 6-13
DH-485 Connections (400 - 600 only)
This section shows connections between a PanelView 400-600
terminal with a DH-485 Communication Module and an SLC or
ControlLogix controller through the AIC+ module.
PanelView Plus 400-600
with DH-485 Module
1784-CP14 Cable
To ControlLogix or SLC Controller
AIC +
RS-232
1761-CBL-PM002 Cable
AB Drives
