154 Rockwell Automation Publication 2711P-UM006E-EN-P - January 2017
Chapter 6 Terminal Connections
Table 76 - PanelView Plus 6 Terminals to Logix Controllers
Protocol PanelView Plus 6 Comm Port
ControlLogix
CH0 (9-pin RS-232)
(DF1)
CompactLogix
CH0 (9-pin RS-232)
(DF1 or DH-485)
DF1
RS-232 (DF1) port (9-pin)
All terminals
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
DH-485
RS-232 (DH-485) port (9-pin)
All terminals
—
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
DH-485 port
700 to 1500 terminals only
Require 2711P-RN6, 2711P-RN6K
—
Use AIC+ module
(1761-NET-AIC)
Connect to Port 3
EtherNet/IP
EtherNet/IP port
All terminals
2711P-RN20 provides additional port - 700 to 1500 terminals
only
Use 1756-EN2T or 1756-ENBT module with
1585J-M type cable or
2711P- CBL-EX04 (4 m/14 ft)
To 1769-L35E, 1769-L23E, 1769-L32E,
or 1768-ENBT module with 1585J-M type cable
or 2711P- CBL-EX04 (4 m/14 ft)
ControlNet
ControlNet port
700 to 1500 terminals only
Require 2711P-RN15S, 2711P-RN15SK
Use 1756-CNB module with ControlNet cable
1769-L35CR, 1769-L32C, 1768-CNB, or 1768-CNBR
with ControlNet cable
DH+ DH+ port
700 to 1500 terminals only
Require 2711P-RN6, 2711P-RN6K
Use 1756-DHRIO module
with
shielded twinaxial cable (1770-CD)
—
Table 77 - PanelView Plus 6 Terminals to Interface Modules
Protocol PanelView Plus 6 Comm Port 1747-AIC
1761-NET-AIC 1761-NET-ENI
Port 1
(9-pin)
Port 2
(8-pin Mini DIN)
Port 3
(DH-485)
Port 2
(8-pin Mini DIN)
DF1
RS-232 port (9-pin)
All terminals
—
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2711-NC21 (5 m/16 ft)
2711-NC22 (15 m/49 ft)
Null modem required
—
1761-CBL-AP00 (5 m)
1761-CBL-PM02 (2 m)
2711-CBL-PM05 (5 m)
2711-CBL-PM10 (10 m)
DH-485
RS-232 port (9-pin)
All terminals
—
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft)
2711-NC21 (5 m/16 ft)
2711-NC22 (15 m/49 ft)
Null modem required
—
DH-485 port
700 to 1500 terminals only
Require 2711P-RN6, 2711P-RN6K
Direct connection to single
AIC with
Belden 9842 cable
(1)
——
Direct connection to
single AIC+ with
Belden 9842 cable
(1)
—
(1) Use serial port on the PanelView Plus 6 terminal with an AIC+ module for a DH-485 network solution.
