Allen-Bradley PowerFlex 6000T Hardware Service Manual

Rockwell Automation Publication 6000-TG100A-EN-P - September 2020 19
Chapter 2 Preventative Maintenance and Component Replacement
Table 4 - Preventative Maintenance Schedule
Interval Period (in years from commissioning date)
Component Location
Component Category
Component/Item 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Isolation Transformer Cabinet
Air-cooling system
Door -mounted Air Filters C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R Top-mounted Cooling Fans
IIIIRIIIIRIIIIRIIIII
Integral Magnetics
Isolation Transformer IIIIIIIIIIIIIIIIIIII
LV Control Voltage Sensing Board IIIIIIIIIIIIIIIIIIII
Power Cell Cabinet
Air-cooling system
Door -mounted Air Filters C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R C / R Top-mounted Cooling Fans
IIIIRIIIIRIIIIRIIIII
Power Cell
Electrolytic Capacitors
(1)
(1) Based on full load/full speed operation at 8700 hours per year at 30 °C (86 °F) ambient temperature. For higher ambient temperatures the replacement should be done sooner, contact factory for details.
IIIIIIIIIIIIRIIIIIII
Misc. HECS IIIIIIIIIIIIIIIIIIII
LV Control Cabinet
Misc. AC/DC Power Supplies IIIIIIIIIIIIIIIIIIII UPS
UPS
(2)
(2) Fully discharge and recharge the UPS batteries every 6 months, to extend battery life.
IIIIIIIIIIIIIIIIIIII
LV Control
Control Pod IIIIIIIIIIIIIIIIIIII Enhanced HIM IIIIIIIIIIIIIIIIIIII LV Control Relays IIIIIIIIIIIIIIIIIIII LV Control Circuit Breakers
IIIIIIIIIIIIIIIIIIII
All Connections
LV Component Terminal & Plug-in Connections
IIIIIIIIIIIIIIIIIIII
Medium Voltage Cable Connections
IIIIIIIIIIIIIIIIIIII
Transformer Secondary Winding Connections
IIIIIIIIIIIIIIIIIIII
Power Cell Input and Output Power Connections
IIIIIIIIIIIIIIIIIIII
General
Enhancements
Firmware ——Rv——Rv——RvRv—Rv——Rv——Rv—— Hardware ——Rv——Rv——Rv——Rv——Rv——Rv——
Operational Conditions
Parameters / Variables I I Rv I I Rv I I Rv I I Rv I I Rv I I Rv I I
Spare Parts Inventory Needs I I Rv I I Rv I I Rv I I Rv I I Rv I I Rv I I
