Rockwell Automation Publication 750-IN100B-EN-P - July 2017 133
Power Wiring Chapter 5
Recommended PE-B1 Jumper Configuration
The PE-B1 power jumper is connected to the power interface circuit board in
the power modules.
Figure 66 - Recommended PE-B1 Jumper Configuration
J5 (PE-B1 IN)
J6 (PE-B1 OUT)
Jumper Shown in the Default Installation Location.
Power Module
