Rockwell Automation Publication 750-IN100B-EN-P - July 2017 49
Prepare for Installation Chapter 3
Frame 11 Bus Supplies Top, Front, and Bottom Views - Dimensions are mm (in.)
See page 51 for optional entry wire bay dimensions.
2606
(102.6)
1000
(39.4)
800
(31.5)
800
(31.5)
36
(1.4)
535
(21.1)
IP21, UL Type 1
2132
(83.9)
IP54, UL Type 12
2291
(90.2)
IP21, UL Type 1
676
(26.6)
IP54, UL Type 12
721
(28.4)
0 (0)
1000 (39.4)
2535 (99.8)
1800 (70.9)
1735 (68.3)
1000 (39.4)
935 (36.8)
450
(17.7)
45
(1.8)
200
(7.9)
200
(7.9)
230
(9.1)
186
(7.3)
1481
(58.3)
200
(7.9)
726
(28.6)
473
(18.6)
45
(1.8)
Signal Cables - Top Entry
Mounting Holes
Input Power Cables - Bottom Entry
Signal Cables - Bottom Entry
Input Bay
Power Bay
Power Bay
