50 Rockwell Automation Publication 750-IN100B-EN-P - July 2017
Chapter 3 Prepare for Installation
Frame 12 Bus Supplies Top, Front, and Bottom Views - Dimensions are mm (in.)
See page 51
for optional entry wire bay dimensions.
83
(3.3)
3206
(126.6)
1000
(39.4)
800
(31.5)
0 (0)
1735 (68.3)
3135 (123.4)
2600 (102.4)
600
(23.6)
36
(1.4)
535
(21.1)
IP21, UL Type 1
2132
(83.9)
IP54, UL Type 12
2291
(90.2)
IP21, UL Type 1
676
(26.6)
IP54, UL Type 12
721
(28.4)
1000 (39.4)
935 (36.8)
450
(17.7)
45
(1.8)
200
(7.9)
200
(7.9)
230
(9.1)
186
(7.3)
1481
(58.3)
200
(7.9)
726
(28.6)
473
(18.6)
45
(1.8)
800
(31.5)
2535 (99.8)
1800 (70.9)
Signal Cables - Top Entry
Mounting
Holes
Input Power Cables - Bottom Entry
Signal Cables - Bottom Entry
Power BayInput Bay Power Bay Power Bay
