Allweiler AEB.E Series - 3.2 Pump Layout Variants

Layout and function
3.2 Layout
Example representation of 2 variants. Further va r iants are
described in the appendix (→ 9.1.2 Sectional drawings,
Page 39).
3.2.1 Ba se version
123
45
67
4
8
9
10 11
1112 13
Fig. 3 Layout – AE, ID design
1 Pressure side 6
Suction side/suction casing
11 Bearing
2
Stator
7
Universal joint shaft
12 Bearing pedestal
3Rotor 8
Shaft seal
13
Top shaf t
4Joint 9
Double casing for shaft seal
1)
5
Double casing for suction casing
1)
10
Shaft seal ring
1)
optional
