Appendix
AE1+1H
Values by size [l]Parameter
2700
Total volume 96.80
Residual liquid quantity 15.63
Tab. 47 Total volume and residual liquid quantity AE1+1H
AE2H
Values by size [l]Parameter
100 200 380 750 1450 2700
Total volume 5.12 9.0 0 17.62 31.36 56.24 96.80
Residual liquid quantity 0.70 1.2 5 2.30 4.67 8.56 15.63
Tab. 48 Total vol ume and residual liquid quanti ty AE2H
AE2+2H
Values by size [l]Parameter
100 200 380 750 1450 2700
Total volum e 5.62 10.00 19.42 35.24 63.84 110.64
Residual liquid quantity 1.20 2.2 5 4.10 8.55 16.1 6 29.47
Tab. 49 Total volume and residual liquid quantity AE2+2H
AE4H
Values by size [l]Parameter
12 25 50 100 200 380 750 1450
Total volume 1.02 1.75 3.23 5.62 10.00 19.42 32.24 63.84
Residual liquid quan tity 0.17 0.32 0.60 1.20 2.25 4.10 8.55 16.16
Tab. 50 Total vol ume and residual liquid quanti ty AE4H
AE2+2V
Values by size [l]Parameter
100 200 380 750 1450
Total volu me 8.93 17.56 31.54 53.76 96.89
Residual liquid quantity 1.25 2.3 4 4.28 8.76 16.50
Tab. 51 Total volume and residual liquid quantity AE2+2V
AE4+4V
Values by size [l]Parameter
25 50 100 200 380 750 1450
Total volume 3.2 2 5.50 9.93 19.56 35.14 61.52 112.09
Residual liquid quantity 0.60 1.12 2.25 4.34 7.88 16.52 31.70
Tab. 52 Total volume and residual liquid quantity AE4+4V
260371 – 176-982/0 BA-2020.05 en-US AE 55
