Allweiler AEB.E Series - Total Volume and Residual Liquid Quantity AE2 E and AEB2 E; AE1 N and AEB1 N; AE2 N and AEB2 N; Total Volume and Residual Liquid Quantity AEB3 N

Appendix
AE2E and AEB2E
Values by size [l]Parameter
50 100 200 380 750 1450 2700 5000
1)
9500
1)
Total volume 1.31 2.31 4.12 7.39 13.11 25.45 49.18
On re quest
Residual liqu id quantity 0.37 0.71 1.31 2.23 4.4 5 8.55 15.70
On re quest
Tab. 41 Total volume and residual liquid quantity AE2E and AEB2E
1) Applies only for AE2E
AE1N and AEB1N
Values by size [l]Parameter
25 50 100 200 380 750 1450 2700
1)
5000
1)
Tota l volume 1.01 1.70 3.12 5.29 9.17 18.09 32.74 55.04 98.88
Residualliquidquantity 0.150.250.460.811.332.514.758.7816.28
Tab. 42 Total volume and residual liquid quantity AE1N and AEB1N
1) Applies only for AE1N
AE2N and AEB2N
Values by size [l]Parameter
12
1)
25 50 100 200 380 750 1450 2700
2)
5000
2)
Total volume 0.73 1.07 1.82 3.37 5.79 10 .07 20.03 36.45 61.96 111.5 2
Residual li quid quantity 0.10 0.22 0.37 0.71 1.31 2.23 4.45 8.55 15.70 28.92
Tab. 43 Total volume and residual liquid quantity AE2N and AEB2N
1) Applies only for AEB2N
2) Applies only for AE2N
AEB3N
Values by size [l]Parameter
12
5
Total volume 0.68 0.68 0.71
Residual li quid quantity 0.06 0.06 0.10
Tab. 44 Total volume and residual liquid quantity AEB3N
AE4N
Values by size [l]Parameter
25 50 100 200 380 750 1450
Total volume 1.19 2.06 3.87 6.79 11.87 23.91 44.14
Residual liquid qu antity 0.34 0.61 1.21 2.31 4.03 8.33 16.15
Tab. 45 Total volume and residual liquid quantity AE4N
AED2N and AEDB2N
Values by size [l]Parameter
38
75
150 300 560 1200 2300 4250
1)
7800
1)
Total volume 1.13 1.96 3.65 6.33 11.05 22.13 40.58 69.4 4 125.08
Residual liquid quantity 0.26 0.50 0.96 1.78 3.09 6.29 12.08 22.25 40.7 8
Tab. 46 Total volume a nd residual liquid quantity AED2N and AEDB2N
1) Applies only for AED2N
54 AE BA-2020.05 en-US 260371 – 176-982/0
