Appendix
Design
IE, ZE ID, ZD
RG
Part
no.
Designation
repair set
Quantity
repair set
Quantity
repair set
Quantity
215 Mechanical seal cover 1 1
218
O-ring
R1 R1 1
219 Mechanical seal R 1 R 1
220 Retaining pin 1 1
9)
232
Shaft seal ring
R1 R1
234 Throttle ring R 1 R 1
235
O-ring
R1 R1
236 Retaining pin R 2 R 2
245
Stud bolt/hexagon head bolt
338
251
Sealing material
11
301 Jointpin R,r 2 R,r 2 R,r 2
302 Joint bush R, r 2
2)
R, r 2
10)
R, r 2
303
Bush for joint pin
R, r 4 R, r 4 R, r 4
304 Joint sleeve R, r 2 R, r 2 R, r 2
305 Joint oil R, r
1)
R, r
8)
R, r
306 Joint clamp R, r 4 R, r 4 R, r 4
307
Universal joint shaft
R1 R1 R1
308 Joint sleeve R, r 2 R, r 2 R, r 2
401 Rotor R, r 1 R, r 1 R, r 1
402
Stator
R, r 1 R, r 1 R, r 1
17)
403
Stator seal, pressure side
R, r 1
11)
R, r 1
11)
404
Stator seal, suction side
R, r 1
11)
R, r 1
11)
501
Gasket for suction casing
R, r 1 R, r 1 R, r 2
502
Screw plug
1
4)
1
503
Seal ring/sealing mater ial
R1
4)
1
504 Discharge casing 1 1 1
505
Suction casing
111
506
Suction casing cover
22
507
Gasket
R2 R2
508
Stud bolt
88
509 Hexag on nut 8 8
512
Reduction flange
11
513
O-ring
R1 1
525 Disk 8 8
601 Nameplate 1 1 1
602 Roun d head grooved pin 4 4 4
603
„Commissioning“ information
plate
111
36 AE BA-2020.05 en-US 260371 – 176-982/0
