Alpine Spas SPA POOL - External Drain Valve; Fountain; Internal Drain; Pump Intakes

76
Theexternaldrainvalvesitsonacabinetpanelononesideofthespa
pool.Attachahoseandtwistandturntoreleasetheowofwater
whendraining.Usingthedrainvalveisexplainedonpage88.
Selectmodelshavefountainswhichpopupandruninconjunction
withthewaterfall.TheyareilluminatedwithanLEDlightaspartof
thelightingpackage.Itiscontrolledviathewaterfallcontroldial.
17
18
EXTERNAL DRAIN VALVE
FOUNTAIN
7. GETTING TO KNOW YOUR SPA POOL
Selecthydrotherapyseatshaveheadrestsasacomfortoptiontoadd
totherelaxationexperience.SomeheadrestshaveLEDlightsbehind
toilluminatethearea.
21
HEADREST
Pumpintakessitinthefoot-wellofthespapool.Waterissucked
throughtheseandthenexpelledbackoutthejets.
15
PUMP INTAKES
Thespapoolwaterdrainsoutthisportwhentheexternaldrainvalve
isreleased.SmallOzonebubblesmayemitfromthispiecefromtime
totime-thisisanormalfunction.
16
INTERNAL DRAIN
Thisisthebuttonpadandtemperaturedisplaypanellocatedonthe
topofthespapoolintowhichvariouscommands,controlsequences
andoptionsforoperatingthespapoolcanbeentered.
Theheartofthespapool.Acomputersystemandheatermakesup
thecontrollerasawholeandcontrolsallcomponentsinthespapool
includingthetopsidecontrolpanel.
19
20
TOPSIDE CONTROL PANEL
SYSTEM CONTROLLER
SPA POOL PARTS LABELED - CONTINUED
