Layout and function
22
AMADRILL+ BAH0040-9 01.19
The creation of tramlines is shown in Figure (Fig. 16) using various examples:
A = Working width of the seed drill
B = Tramline spacing (= working width fertiliser spreader/field sprayer)
C = Tramline rhythm (entered on the control terminal)
D = Tramline counter
(during operation, the field passes are numbered consecutively and displayed on the control
terminal).
