Amazone AmaDrill+ - Calibration Test on Seed Drills with Vario Gearbox

Settings
AMADRILL+ BAH0040-9 01.19
33
6.7.4 Calibration test on seed drills with Vario gearbox
without seed rate remote control
Calibration test on cam wheel seed drills (e.g.
D9) and pneumatic seed drills (e.g. AD-P) with
Vario gearbox without seed rate remote control
(Fig. 29).
Fig. 29
1. Prepare the seed drill for the calibration test as described in the seed drill operating manual (set
up calibration trough, etc.).
2. Press
.
3. Using the
or buttons, enter the code number (see table) of the metering wheel.
Mechanical seed drills Pneumatic seed drills
Metering wheel
Normal seed
metering wheel
Fine seed
metering wheel
Metering roller
Code number
3 1 See table Fig. 62, Seite 66
4. Press
.
5. Press
.
6. Enter the desired spread rate (kg/ha).
7. Press
.
8. Read the scale value (e.g. 50) for the first calibration test from the seed drill operating manual.
9. Press
.
10. Press the
or button.
 Enter the scale value for the first calibration test on the control terminal.
11. Set the gearbox setting lever (Fig. 29/1) to the scale value and fasten with the knurled screw (Fig.
29/2).
