Tables
60
AMADRILL+ BAH0040-9 01.19
Mode 15 Code Calibration factor
(only required on machines with electric full metering unit)
1,000
Factory-set value
After replacing the metering roller in the
metering housing, set the calibration factor
to 1,000.
0,0000 –
9,999
Adjustable values
Mode 16 Code
Setting the working position sensor: (Mode 16 only appears when an
analogue working position sensor has been selected in mode 13.)
0.5 to 4.5
Analogue
sensor
When lowering the machine, the metering motor switches on
when the set height is reached.
Enter the height as voltage value (0.5 to 4.5 V).
The value in Mode 16 cannot be smaller than the value
in Mode 13.
Smaller value: switch on the metering motor
at low height
Higher value: switch on the metering motor
at greater height
Mode 17 Code Segment distributor head
0
Implement does not have a segment distributor head
1
Implement has one or several segment distributor heads
Mode 18 Code Sensor that activates the tramline counter
0
Working position sensor
1
Track marker sensor
Code number input, see section Enter implement data, page 26.
