3-12 | Model 888 ATEX IECEx Tail Gas Analyzer
Item Description Part No.
FV1 Valve, Sample Inlet 271446001
DEM Demister Assembly 883026901
Demister Pad, Teon 272177001
Demister Pad, Stainless Steel 271653001
FV2 Valve, Sample Return 273383001
CELL Cell Assembly, 1% H2S / 2% SO2 883034901
Cell Body, 1% H2S / 2% SO2 883077001
CELL Cell Assembly, 2% H2S/4%SO2 883034902
Cell Body, 2% H2S/4%SO2 883077002
Window, Fused SIlica, 1.5” 200887001
O-ring, Viton, 028 202813026
Gasket, Teon 880042001
ASP Aspirator 407300902
FV3 Valve, Steam/Cell Isolation 883096001
CV1 Check Valve, Aspirator 203790001
CV2 Check Valve, Zero Flush, 200 micron orice 883035001
O2 Orice, Zero Flush, 200 micron 273454001
O1 Orice, Pressure Transducer Purge, 50 micron 273455001
O3 Orice, 400 micron 272080001
HE1 Heat Exchanger, Aspirator Drive, Alum Tube N/A
HE2 Heat Exchanger, Zero Flush, Alum Tube N/A
PCV1 Pressure Regulator, Manifold, 0-100 psig 301-0431
PCV2 Pressure Regulator, Aspirator, 0-30 psig 301-0430
PS1 Pressure Sensor, Manifold, 0-100 psig 403464902
PS2 Pressure Sensor, Aspirator, 0-30 psig 403464903
S1,S2,S3,
Solenoid Valves (Demister, Zero Flush,
Steam Blowback/Cell Isolation)
301-0424
PV1 Valve, Proportional Control, Aspirator 883038901
RTD1 RTD, Cell 883095001S
RTD2 RTD, Demister 273402001
RTD3 RTD, Flange 883095002S
PT Pressure Transducer, 0-50 psia 273291001
GA1 Gauge, Aspirator, 0-30 psig 251744000
PCV3 Pressure Regulator, Purge, 0-60 psig 203188003
PI1 Gauge, Purge, 0-60 psig 273472001
Table 1. Parts Legend - Refer to Figure 3-2.
