Installation and Start Up
| 3-23
When the analyzer components reach operating temperature, the control-
ler will perform an auto-zero of the photometer and then enter Period 3,
Sample Flush.
Sample will not flow through the cell until positive flow is attained by
adjusting the aspirator pressure.
Allow 2-4 hours for complete thermal stabilization of sample cell and
demister.
Setting the Sample Gas Flow
To set the sample gas flow, navigate to the menu item CONFIGURE on
the HOME screen and press the (ENTER) key.
Figure 3-8a. Controller Home Screen.
Use the right and left navigation arrows to advance to the PRESSURES
screen. Press the ENTER key to select the PRESSURES menu.
Figure 3-8b Pressure Menu
Figure 3-8c. Pressure Conguration
Use the arrow keys to navigate to Aspirator Pressure Configuration and
press the ENTER key.
!
