Specications
| 2-1
SPECIFICATIONS
Model 888 Tail Gas Analyzer
Ranges
Standard Range:
0-2% H
2
S and 0-1% SO
2
High Range:
0-4% H
2
S and 0-2% SO
2
Other ranges available upon request.
Performance
All performance specications are based on normal
operation that includes periodic zero and photo span
calibration.
Accuracy ± 1% of full scale range
Reproducibility ±1% of full scale range
Repeatability <1% of full scale range
Noise ± 0.5% of full scale range
Zero Drift <0.5% of full scale range
Response Time
90% in less than 15 seconds, typical with photo
noise at default
Cell Battery Type
Primary Lithium poly-carbon monouoride (Li/CF(n))
Size: Coin
Operating Temp: -30 °C to +80 °C
Nominal Voltage = 3.3 V
Minimum Internal Resistance = 3.1 mΩ
Capacity = 190 mAh
Weight: 2.5 g
Dimensions = 3.2mm (H) X 20mm (D) +/- 0.3mm
Calibration
Factory calibrated; Automatic calibration capability
(no hazardous or toxic calibration gases are needed)
