Essential Health & Safety Requirements | 25
Figure 4b.
Analyzer mounting,
door clearance.
48.75
[1238.3]
FRONT VIEW
BOTTOM VIEW
27.75
[704.85]
DIMENSIONS ARE IN INCHES, [mm]
